3” SUSPENSION LIFT KIT 2018-2022 JEEP WRANGLER JL (4DR)

Take your Wrangler JL to new heights with this 3" lift kit from Zone Offroad. This 3" lift kit includes everything needed from full length coil springs and bump stop extensions to longer sway bar links, rear track bar bracket and lower cam washers. Get the look, performance, and capability your Jeep deserves with clearance for up to 37" tires.

QUICK SPECS

Front Lift Height: 3"

Rear Lift Height: 3"

Material: Steel

Front Lift Method: Coil Springs

Rear Lift Method: Coil Springs

Lift Type: Lift Kit

Wheel Size: 17 x 9

Back Spacing: 4.5"

Max Tire Size: 35 x 12.5

Is Adjustable: No

Cutting Required: No

Accommodates Factory Wheels: No

Welding Required: No

IN THE BOX

All Necessary Mounting / Installation Hardware
Bump Stop Extensions
Coil Springs
Sway Bar Links
Track Bar Relocation Bracket

FEATURES

Front and rear replacement coil springs s to lift
Front and rear bump stop extension to properly engage bump stops during hard compression
Front and rear sway bar links to correct sway bar operating angle
Front lower cam washers to correct caster
Rear track bar bracket to recenter axle under vehicle

IMPORTANT NOTES

Suits 4 Door Models ONLY
Does not fit Diesel Models
Non-Rubicon comes from factory at lower ride height, will net slightly more lift final stance the same for all models.
Stock wheels cannot be reinstalled without spacers due to rear sway bar interference.
Will not fit 4xe models.
Will not fit Rubicon 392 models.

ALSO INCLUDED

PERFORMANCE ELITE SERIES 2.5 RESERVOIR SHOCK (PAIR) - ADJUSTABLE - 883-26-050

Performance Elite Series 2.5 Reservoir smooth body shocks give you enhanced ride quality and the control you need when heading off the pavement. They take their design from our Off-Road race shocks, so they've been thoroughly perfected in brutal conditions that you will probably never see. Our athletes push the boundaries in competition to develop race-proven performance you can bolt onto your Truck or SUV.

The external reservoir allows for increased oil and nitrogen capacity while delivering a striking race look. Applications are available to fit most stock and lifted Trucks and SUVs. Our complete line of bolt-on, Performance Elite shocks provide improved damping in any terrain. Experience for yourself the incredible performance and precise control that Performance Elite Series 2.5 Reservoir shocks deliver.

Body	2.5" impact extruded and CNC machined 6061-T6 hard anodized aluminum body resists rust over time
Body Plating	Hard-anodized for a durable finish
Reservoir	External reservoir design separates shock oil from the high-pressure nitrogen
Components	Black-anodized, CNC-machined 6061-T6 billet aluminum
Shaft	7/8" hard chrome plated heat-treated alloy steel
Piston	Race-developed high-flow piston design
Valving	Application specific valving to maximize performance
Seals	Redundant sealing pack system main seal, wiper seal, scraper seal
Bearing	PTFE-lined, heat-treated, alloy steel spherical
Adjuster Type	DSC - Dual Speed Compression
Extended	26.510
Compressed	16.340
Travel	10.170
Top Mount	Eyelet
Bottom Mount	Eyelet
Fitment notes	Includes Universal Bracket

PERFORMANCE ELITE SERIES 2.5 RESERVOIR SHOCK (PAIR) - ADJUSTABLE - 883-26-054

Performance Elite Series 2.5 Reservoir smooth body shocks give you enhanced ride quality and the control you need when heading off the pavement. They take their design from our Off-Road race shocks, so they've been thoroughly perfected in brutal conditions that you will probably never see. Our athletes push the boundaries in competition to develop race-proven performance you can bolt onto your Truck or SUV.

The external reservoir allows for increased oil and nitrogen capacity while delivering a striking race look. Applications are available to fit most stock and lifted Trucks and SUVs. Our complete line of bolt-on, Performance Elite shocks provide improved damping in any terrain. Experience for yourself the incredible performance and precise control that Performance Elite Series 2.5 Reservoir shocks deliver.

Body	2.5" impact extruded and CNC machined 6061-T6 hard anodized aluminum body resists rust over time
Body Plating	Hard-anodized for a durable finish
Reservoir	External reservoir design separates shock oil from the high-pressure nitrogen
Components	Black-anodized, CNC-machined 6061-T6 billet aluminum
Shaft	7/8" hard chrome plated heat-treated alloy steel
Piston	Race-developed high-flow piston design
Valving	Application specific valving to maximize performance
Seals	Redundant sealing pack system main seal, wiper seal, scraper seal
Bearing	PTFE-lined, heat-treated, alloy steel spherical
Adjuster Type	DSC - Dual Speed Compression
Extended	28.600
Compressed	17.430
Travel	11.170
Top Mount	Eyelet
Bottom Mount	Eyelet
